Operating frequency: 433.92MHz
2 to 5 digit access codes
Capable of storing 1 to 24 different access codes
Access codes can be programmed to either primary relay 1 or secondary relay 2
Technical specifications
Number of keys: .................................................................................12
Number of channels:.......................................................................4 + 2
Supply: .......................................................................................3,6 Vdc
Battery duration: ................................................ .........about 24 months
Battery type:...............................................................Lithium LS14500
Current consumption: ( transmission ) ........................................28 mA
stand-by.........................................................................................0,8 uA
Operating frequency: ..........................................................433.92 MHz
Modulation: .............................................................................AM/ASK
E.r.p.:..............................................................................................6 mW
Security Code combinations number: ...........................................19683
User security code number:.............................................................24+1
Transmission duration: ...............................................until press / 1 sec.
Range in open space: ................................................from 150 to 700 m
Operating temperature: .........................................
Dimensions: .............................................................
Weight:.........................................................................................
IP Protection Grade: ........................................................................IP54
